Baumer NE216 Betriebsanleitung Seite 42

NE216
42
Technical data - mechanical design
Ambient temperature
Storing temperature
Relative humidity
E-connection
Core cross-section
Protection DIN EN 60529
Operation / keypad
Housing type
Dimensions W x H x L
Installation depth
Mounting
Cutout dimensions
Materials
Weight approx.
Technical data - trigger level
Comparator inputs
Inputs
Input level
Input level Low
Input level High
Input resistance
Relay outputs
Switching voltage max.
Switching current max.
Switching capacity max.
Relay responding time
Electronical outputs
Switching voltage max.
Switching current max.
Residual voltage
www.baumer.com
0...+50 °C
-20...+70 °C
80 % non-condensing
Plug-in screw terminals
1.5 mm²
IP 65 face with seal
Membrane with softkeys
Built-in housing
48 x 48 x 100 mm
100 mm
Clip frame
45 x 45 mm (+0.6)
Housing: Makrolon 6485 (PC)
Keypad: Polyester
150 g (12...30 VDC / 85...265 VAC)
260 g (24/48 VAC)
Input circuit
PNP- / NPN-logic
Programmable
0...2 VDC
3...40 VDC
3 k
Output circuit
250 VAC / 110 VDC
1 A
150 VA / 30 W
5 ms
Output circuit
Optocoupler short-circuit proof
40 V
25 mA
<1 V
