Baumer NE216 Betriebsanleitung Seite 32

NE216
Modify
Modify
Modify
Example In the case of a length measurement by means of encoder and
32
Current count
After the counter has been turned on or upon selection via
appears for one second on the display. The current count is then
displayed for reading.
➜ Read count PC.
Clear ➜ Press
Preset P1
Read ➜ Press
„P1" appears for one second on the display. The preset P1 is
then displayed for reading.
➜ Enter preset P1 via
Press
Preset P2
Read ➜ Press
„P2" appears for one second on the display. The preset P2 is
then displayed for reading.
➜ Enter preset P2 via
Press
Start count SC
Read ➜ Press
„SC" appears for one second on the display. The display then
jumps to the current start count SC.
➜ Enter SC via
Press
Totalizer tot
Read ➜ Press
„tot" appears for one second on the display. The display then
jumps to the current total.
If the value 99999 is exceeded, its display will be shown in two steps.
First step: Display of the first 5 digits.
Second step: marked by „H", Display of 6th, 7th and 8th digits.
Display of each value for approx. 3 seconds
Clear ➜ Press
Scaling factor SF
The scaling factor allows the display of fractions or multiples of the
counting pulses.
Setting range: 0.0001 to 999.99
Setting ex factory: 1.0000.
cyclometer, where the circumference of the cyclometer measures
200 mm and the encoder supplies 500 pulses per revolution, the
measurement is to be displayed in mm.
The scaling factor is calculated as follows :
Scaling factor =
www.baumer.com
key.
key.
and
key.
key.
and
key.
key.
and .
key.
key.
key.
Circumference
Pulses
.
.
200
= = 0.4000
500
, „C"
