NE216
Enter code Enter code via
Wrong code If a wrong code has been entered, „Error" is displayed as long as
Correct code unknown If the correct code is not known, please return the counter to the
Select programming lines Select the required programming line via
Jump back to
programming line
Modify operation
parameters
Leave programming It is possible to shut down the programming at any time by pushing
Reset to factory setting Turn on instrument and press
Line 1
Line 2
Line 3
Line 4
Line 5
Line 7
34
and
Press key to confirm.
The instrument switches from the operator to the programming level.
remains pushed. After 15 s the instrument switches automatical-
ly back to the operator level.
supplier or effect reset to factory setting.
number will be displayed.
For quick sweep, keep
By keeping depressed and by operating
back within the programming lines.
Select the decade to be changed via
The selected decade blinks.
Enter the value by pushing
Press key to confirm.
and simultaneously (keep depressed for 2 seconds).
already programmed are set back to the factory setting. „ClrPr"
appears on the display.
Programming field 1
Here it is possible to select and modify all operation parameters.
The operation parameters that are disabled for the operator are also
displayed.
PC - Main counter (current count)
P1 - Preset 1
P2 - Preset 2
SC - Start count
tot - Totalizer
SF - Scaling factor
The dash line indicates the end of the first programming field.
Switch to programming field 2 by pushing
