For the variant with flaps, open all flaps of the cable grommet carefully.

6.12 Assembly of cable guide

Both a horizontal cable guide
17
(sock tube)
cables (e.g. mains cable, telephone cable, power cable, LAN cable, etc.) under the tabletop.
This consists of 3 clips incl. 3 screws, which you can screw on as required. Place these clips in a
position of your choice underneath the tabletop and screw them in place with the screw.
TIP: Position a clip plumb-vertically over the end of a leg where you can later attach the vertical
cable guide. You can now clip any cables into the cable guide.
6 0
13
, which is mounted under the tabletop, and a vertical cable guide
are supplied with the table. The horizontal cable guide is intended for routing
