Assembly Of 500/600 Cm Tabletop Control Unit - Cor Level System Bedienungsanleitung

GB
9
Position the cable guide under the holes provided in the tabletop and attach the cables using
12
the screws supplied. Position the plug connections in the cable guide and check that all cables
are not crushed, sheared or damaged.

6.10 Assembly of 500/600 cm tabletop control unit

14 16
Position both control units in the centre of the tabletop and lay the connecting cables in
the directions shown.
5 6
