6.4 Assembly of tabletop

GB
Turn the tabletop freely in the air and place it on the pre-assembled underframe so that all the
fixing holes are positioned over the threaded sockets provided. Attach the tabletop using the
9
screws supplied and tighten them all firmly..
6.5 Connecting the control unit
15 16
Plug the connecting cables into the sockets 1-3, the mains cable into AC and the control
14
panel plug into A1 on the control unit . Check that all cable connections have not been crushed,
sheared or damaged in any way.
4 6
