6.2 Pre-assembly of under frame
IMPORTANT NOTE ON ASSEMBLY:
When loosening the cable ties on the legs, it is essential to ensure that the legs do not rotate.
Rotating can change the factory height setting and, in the worst case, cause the motor to malfunction.
Please ensure that there is a gap of 10-20 mm between the tube and the screw-on plate.
To assemble the underframe, insert any leg 3 into the cross beam 1 and attach it using the
11
supplied screws and nuts
Now insert the second leg
12
nuts . Tighten the screws securely.
12
. Tighten the screws firmly.
3
into the cross beam 1 and attach it using the supplied screws
GB
11
and
4 3
