6.8 Assembly of control unit

GB
14 16
Connect the control unit by inserting the connecting cables into the sockets 1, 2, 3 and
15
4, the mains cable into the socket AC and the plug from the control panel into the socket A1.
Check that all cable connections are not crushed, sheared or damaged.
Position the control unit in the centre under the tabletop and lay the connecting cables in the
directions shown.
5 4
