8.2 Switching the table on

The table is ready for operation as soon as the mains plug is plugged in and the power supply is
established.

8.3 Operating the height adjustment

When you are standing in front of the table, the control panel (toggle switch) for moving the table
is mounted on the right side under the table top.
Release the toggle switch when you have reached the desired position.
The travel range of the table height is from 70 cm to 115 cm.
Collision protection:
There is a built-in stopper about 10 cm above the lowest position. This is to protect the table as
well as the operator, other persons and foreign bodies from injury, crushing and destruction.
By pressing the button again, the table top continues to move.
8.4 Control panel – other uses
A
Symbol
Bell (Fig. A)
Star (Fig. B)
Press and hold the toggle switch up to raise the table.
Press and hold the toggle down to lower the table.
B
Description
Reminder
Favourites
The control panel has three buttons on the front.
Pressed individually or in various combinations,
these keys have different functions.
Funktion
Set reminder
Save favourite position
GB
5 5
