6.2 Pre-assembly under frame 300/350 cm
GB
IMPORTANT NOTE ON ASSEMBLY:
When loosening the cable ties on the legs, it is essential to ensure that the legs do not rotate.
Rotating can change the factory height setting and, in the worst case, cause the motor to malfunction.
Please ensure that there is a gap of 10-20 mm between the tube and the screw-on plate.
Hook one side of the cross beam 1 into the suspension sockets of a underframe 2 using the
pre-assembled screws. Tighten both screws firmly.
Hook the other side of the cross beam 1 into the suspension sockets of the second underframe 2
using the pre-assembled screws. Tighten the two screws firmly.
