8.3 Operating the height adjustment

When you are standing in front of the table, the control panel (toggle switch) for moving the table
is mounted on the right side under the table top.
Collision protection:
There is a built-in stopper about 10 cm above the lowest position. This is to protect the table as
well as the operator, other persons and foreign bodies from injury, crushing and destruction.
By pressing the button again, the table top continues to move.
8.4 Control panel – other uses
A
Symbol
Bell (Fig. A)
Star (Fig. B)
B
Description
Reminder
Favourites
Press and hold the toggle switch up to
raise the table.
Press and hold the toggle down to
lower the table.
Release the toggle switch when you
have reached the desired position.
The travel range of the table height is
from 70 cm to 115 cm.
The control panel has three buttons on the front.
Pressed individually or in various combinations,
these keys have different functions.
Funktion
Set reminder
Save favourite position
