Unpacking; Before Commissioning; Assembly And Operation - Scheppach Basa3 Originalbetriebsanleitung

WARNING: The specified sound emission values are
only valid if the same operating and installation condi-
tions apply. Other operating and installation conditions,
e.g. a different work process, can lead to higher noise
emissions with the risk of underestimation.
WARNING: The specified noise emission values are
not exposure values. Although there is a correlation
between emission and exposure values, the noise
emission values cannot be used to reliably determine
whether or not further precautionary measures are re-
quired. Factors that influence the actual level of expo-
sure are the actual work process, the characteristics of
the work area and other neighbouring noise sources
in the plant.
Sound power level L
Wa
Idling
Sound pressure level L
pA
Idle
Working
Uncertainty K / K
WA pA
Wear hearing protection!
Exposure to noise can cause hearing loss.
Keep the noise level and vibration to a minimum!
• Only use faultless devices.
• Maintain and clean the device at regular intervals.
• Adapt your working methods to the device.
• Do not overload the device.
• Have the device checked if necessary.
• Switch the device off if it is not in use.
7.

Unpacking

• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, keep the packaging until the expiry of
the warranty period.
• Familiarise yourself with the product by means of
the operating instructions before using for the first
time.
• With accessories as well as wearing parts and re-
placement parts use only original Scheppach parts.
38 | GB
Spare parts can be obtained from your specialist
Scheppach dealer.
• When ordering please provide our article number
as well as type and year of manufacture for your
device.
m Attention!
The device and the packaging are not children's toys!
Do not let children play with plastic bags, films or small
parts! There is a danger of choking or suffocating!

8. Before commissioning

m ATTENTION!
Always make sure the device is fully assembled
before commissioning!
80.3 dB
Prepare the workplace where the machine is to be
100.2 dB
located. Make sufficient space to enable safe, prob-
lem-free working.
64.1 dB
82.9 dB
The machine is designed for working in enclosed
4 dB
spaces and must be set up securely on a level and firm
surface. Stability is ensured by fastening with 4 frame
brackets and 4 hexagonal bolts M6x12, each with nut
and washer, to a workbench or fixed base frame on the
floor. (Fig. 22, 23).
9.

Assembly and operation

Observe the safety instructions before the com-
missioning.
m Attention!
All protective devices and covers must be installed be-
fore any work is carried out on the machine. The top
and bottom band wheel is clad by a firmly attached pro-
tection and a moveable housing cover. The machine is
switched off when the housing cover is opened. It can
only be switched on with the cover closed.
• The saw table must be mounted correctly.
• The saw band must be able to run freely.
• In case of previously machined wood, be aware of
any foreign bodies, such as nails or screws, etc.
• Before pressing the on/off switch, make sure that
the saw band is correctly fitted, and that moving
parts run smoothly.
• Before connecting the machine, make certain that
the data on the type plate matches with the mains
power data.
