Scheppach HM216 Originalbetriebsanleitung Seite 28

6 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
7 Technical data
AC motor
Nominal power S1
Operating mode
Idle speed n
0
Carbide saw blade
Number of teeth
Maximum tooth width of the
saw blade
Pivot range
Mitre cut
Saw width at 0°
Saw width at 45°
Saw width at 2 x 45°
(double mitre cut)
Protection class
Weight
Laser class
Laser wavelength
Power of laser
Subject to technical changes!
* = may not be included in the scope of delivery!
Operating mode S6
Uninterrupted periodic operation. The mode comprises of
a start-up period, a time with constant load and an idle
time. The operating time is 10 mins, the relative duty cy-
cle is 25% of the operating time.
28 | GB
220 - 240 V~/
50 Hz
1700 Watts
S6 25%* 2000 W
4700 rpm
ø 216 x ø 30 x 2.8 mm
24/48*
3 millimeters
-45 ° / 0° / +45 °
0° to 45° to the left
340 x 65 mm
240 x 65 mm
240 x 38 mm
II /
approx. 12.0 kg
2
650 nm
< 1 mW
www.scheppach.com
The workpiece must have a minimum height of 3 mm
and a minimum width of 10 mm. Make sure that the
workpiece is always secured with the clamping de-
vice.
Noise data
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L
wA
Uncertainty K
wA
The specified noise emission values have been measured
in accordance with a standardised test procedure and can
be used to compare one power tool with another.
The specified device emissions values can also be used
for an initial estimation of the load.
WARNING
The noise emission values can vary from the
specified values during the actual use of the
power tool, depending on the type and the
manner in which the electric tool is used, and
in particular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
8 Before first use (Fig. 3)
1. Loosen the pre-installed tilt protection (33) on the un-
derside of the saw, pull it out completely and secure it
again using the Allen key (D).
2. The product must be securely installed. Fasten the
product to a workbench, machine stand or similar. In-
sert 4 screws (not included in the scope of delivery)
into the holes on the fixed saw table (19). Tighten up
the screws.
3. Set the adjustment screw (15) to the level of the table-
top to prevent the product from tipping over.
• Prior to commissioning, all covers and safety devices
must be mounted correctly.
• The saw blade must be able to run freely.
• In case of previously machined wood, be aware of any
foreign bodies, such as nails or screws, etc.
• Before pressing the on/off switch, make sure that the
saw blade is correctly fitted, and that moving parts run
smoothly.
• Before connecting of the product, make certain that
the data on the type plate matches with the mains
power data.
96.5 dB
3 dB
109.5 dB
3 dB
