ENVIRONMENT
The device is delivered in a package to protect it against any possible
transport damage. The packaging is made from non-processed
material and can be recycled. Throw the materials to appropriate
colour containers for selective waste collection.
Protect the environment and do not throw used batteries
into household wastes. Return them to the point of sale
or a special recycling centre.
Used electrical equipment (including the computer and
power supply) are recyclable. Do not throw them out with
household waste as they may contain substances dangerous to the
health and environment. You can actively contribute to sustainable
use of natural resources and the protection of the natural
environment by handing the used device to a recycling centre for used
electrical devices.
ASSEMBLY
The device must be assembled carefully by an adult. In case of doubt,
ask a more experienced person for help.
•
Prior to the assembly, make sure the set contains all
the listed elements and whether none of the parts was
damaged during transport. If any parts are missing or you have
any other reservations, contact the seller.
•
Have a look at the drawings and explanations and follow the
assembly manual when assembling the device.
•
Be careful during the assembly. There is a risk of injury when
using the tools and parts.
•
Remember to keep your surroundings safe. Do not let tools
and parts lie around in chaos. Remember that plastic foil and
bags pose o suffocation risk to small children.
•
Assembly parts necessary for a specific step in
the assembly manual are shown in pictures and included in
instructions. Use the elements indicated in the assembly
manual.
•
Do not tighten parts completely during the first stages
of the assembly. Tighten connections after all parts are placed
and fitted properly.
•
The manufacturer may have assembled some parts.
ASSEMBLY DIAGRAM (→ See page 2)
ATTENTION! Do not use parts other than those provided by the
manufacturer.
PARTS LIST
NO.
DESCRIPTION
1
Main frame
2
Bottom frame
3
Treadmill columns
4
Upper frame
5
Motor frame
6
Running board support
7
Front roller
Rear roller
8
9
Cylinder
10
Gear plate
11
Gear belt
12
Multi-ribbed belt
13
Control computer
14
Upper engine cover
15
Lower engine cover
16
Rear roller bezel - left
17
Rear roller bezel - right
18
Side slat
19
Transport wheel
20
Handrail handle cap
21
Handrail foam cover
22
Foot cushioning
23
Rubber cushioning pads
24
Power cable
25
Tilt adjuster
26
Tilt adjuster lock
27
Rubber shock pads
28
Frame profile cap
29
Motor
30
On/Off switch
31
Power cable
32
Single cable
33
Pulse sensor / Start/Stop quick start button
Pulse sensor / Quick change speed + / -
34
buttons
35
Top connection cable
36
Safety key
37
Screw M8*50
38
Screw M8*12
39
Screw M8*16
40
Screw M8*40
41
Screw Φ10*15*(M8*10)
42
Screw M8*20
43
Screw M8*42 20
44
Screw M8*30 15
45
Foam glue
46
Screw M8*45 20
47
Screw M8*32
48
Screw M6*25
49
Screw
50
Screw
51
Screw ST4.0*30
52
Screw ST4.2*20
53
Screw ST4.2*16
54
Screw ST4.2*16
55
Nut M8 S13
56
Washer Φ9* Φ16*t1.0
57
Washer Φ11* Φ 20*t1.5
58
Resilient washer D8
59
Washer Φ5.2* Φ10*t1
60
Computer cable
61
Wrench S17 / S13
62
Wrench S6 / 80*80 mm
ASSEMBLY MANUAL (→ See page 3)
CAUTION! Follow the steps below during the assembly and use tools
supplied with the product. Prepare sufficient space for the assembly
operation. It is advisable to assemble the product with another person
because of the weight of some elements.
FOLDING AND UNFOLDING (→ See page 6)
QUANTITY
1
FOLDING THE DEVICE
NOTE! Before assembling, check carefully that all screws are
1
tightened.
2
NOTE! Be careful with your hands and fingers when folding so that
1
they do not get crushed.
1
Lift the running belt of the device to the horizontal position until the
1
lock clicks.
1
1
UNFOLDING THE DEVICE
1
PLEASE NOTE! Ensure there are no third party or animals in the
1
immediate treadmill vicinity when its belt is lowered.
1
Hold the running belt and release the folding lock (indicated with the
1
arrow). Lower the belt to the railing level. The belt will now descend
1
automatically.
1
1
ADJUSTMENTS
1
Levelling
1
Level the device by rotating the levelling feet in the rear and front
2
base.
2
2
ADJUSTING RUNNING BELT INCLINATION
2
The inclination of the running belt of the treadmill can be adjusted.
4
You can set one of the three inclinations by changing the position of
8
the inclination adjustment lock as shown in the picture.
1
2
2
2
EN
2
4
2
2
6
4
2
2
2
3
2
4
1
2
4
2
1
4
5
2
6
2
4
2
6
19
4
10
16
2
8
1
1
1
1
16
