INSPECTION AND MAINTENANCE DATA MAINTENANCE
Item
1
2
3
4
5
6
7
8
9
10
11
Assembly
Gearbox
Hydraulic system
Hydraulic system
Wheels
Electrical system:
Traction motor
Pump motor
Steering motor
Control circuit
Electric motors:
Traction motor
Pump motor
Steering motor
aattery
Mast and steering axle
Mast and chain guide
Electro-magnetic brake
Steering chain
Aids!
Lubrieants
Gearbox oil
Hydraulic oil
Filter element
Traetion wheel
Fuses
Fuses
Fuses
Fuses
Carbon brushes
Carbon brushes
Carbon brushes
Distilled water
Vaseline
Grease
Chain spray
Feeler gauge
Capaeityl
Settings
Gearbox 4.5 I
40 I
Mesh
=
25,um
Torque 150 Nm
1 x 250 A
1 x 250 A
1 x 25 A
6x 15 A
New 28 mm min. 14 mm
New 22 mm min. 11 mm
New 22 mm min. 12 mm
As required
As required
As required
As required
Gap 0.3 - 1.0 mm
Deflection 5 - 10 mm
RECOMMENDED OllS AND lUBRICANTS
Hydraulic oil
ISO VG 68 H-L or H-LP aec. to DIN 51524 (faetory filling)
Recommendation for normal duty:
Hydraulic oil H-L or H-LP ISO VG 68
average oil temperature 60 - 80°C
Hydraulic oil recommendation for heavy duty:
Hydraulic oil H-L or H-LP ISO VG 100
for heavy and multi-shift duty, operation in warm climate
zones or at high ambient temperatures,
average oil temperature over 80°C
Hydraulic oil recommendation for light duty at low am-
bient temperatures:
Hydraulic oil H-L or H-LP ISO VG 46
114
for light and normal duty in cold climate zones, average
oil temperature below 60°C
NOTE
The foregoing recommendations are only approximate
values. In ease of doubt, we recommend eontacting your
authorized dealer.
Motor bearing grease
High-temperature grease with Walk penetration 255 - 295
DIN 51804, for temperatures ranging from -25°C to
+220
o
C. Dropping point at 270°C to 300°C.
Gearbox oil
Use only olls of elassification API GL5 SAE 90
(to DIN 51512).
Multipurpose grease
Penetration grade 2, to ASTM 265-295 1110 mm.
Chain spray
Chain spray
Battery grease
Vaseline
•
•
•
•
