ENGLISH
OPERATING INSTRUCTIONS
SELECT PRESAVED CABLE TYPES PRIOR TO TESTING:
1. From the Home Screen, use the arrow buttons
Coax)
2. Press the soft key Button #2
to select Velocity of Propagation (VOP)
5
3. Use the arrow buttons or soft keys buttons #2
the enter button
to select the type of cable you are testing for the most accurate results
12
CREATE CUSTOM CABLE TYPE PRIOR TO TESTING:
NOTE: Must have cable connected to data tester to create custom cable type accurately
1. From the Home Screen, use the arrow buttons
2. Press the soft key Button #2
and #3
5
6
enter button
to select "ADD NEW"
12
3. Select Soft Key Button #2
to edit the name
5
4. Use the arrow buttons to navigate to TYPE and select by hitting Enter
buttons to scroll between Data, Voice, and Coax and hit Enter to confirm selection.
5. Use the arrow buttons to navigate to PAIR and select by hitting Enter
buttons to scroll between pair options depending on cable type being tested. NOTE: When Testing Data
cables, select PAIR 4-5 for best results. When Testing Voice Cables, recommended PAIR 2-3 for best
results. When Testing Coax Cables, recommended PAIR 7-8 for best results.
6. To Enter Known Velocity of Propagation (VOP) Percentage or Length Value, use the arrow buttons to
navigate to Velocity of Propagation (VOP)/Length field and select enter.
7. Use the up or down arrow buttons to scroll over either Velocity of Propagation (VOP) or LENGTH, the
selected value will be highlighted ORANGE, and hit soft key button #2
change values and select soft but key #4
7
NOTE: Changing either the Velocity of Propagation (VOP) percentage or Length may change the other
value as they are linked.
8. Select Soft key Button #4
to Save Custom Cable Type
7
OPERATING INSTRUCTIONS
RJ45 WIREMAP TESTING AND LENGTH MEASUREMENT
1. Plug one end of an RJ45-terminated cable into the RJ45 port
the Test + Map™ ID Remote
.
1
2. From the Home Screen, use the Arrow Buttons
the Enter Button
.
12
3. The tester will automatically begin testing and the LCD screen will display the results.
4. Press the Enter Button
to test again.
12
MEASURING LENGTH TO FAULTS (CATEGORY, TWISTED PAIR, DATA CABLE)
If fault is a SHORT:
5. While measuring a twisted pair cable, if there is a short between twisted pairs (i.e. a short between wires
1-2, 3-6, 4-5 or 7-8), the tester will display "SHORT" and show a red line between the shorted wires in the
Wiremap section
. The tester will also indicate the approximate distance to the short location.
A
6. If there is a short between non-twisted pair wires, the tester will indicate and display "SHORT" on all affected
wire pairs. For example, if there is short between wire #1 and wire #3, the tester will display "SHORT" on both
wire pairs 1-2 and 3-6 and show a red line between the shorted wires in the Wiremap section
will also indicate the approximate distance to the short location.
If fault is an OPEN:
1. While measuring a twisted pair cable, if there is an open wire pair, the tester will display "OPEN" and show a
red
X
for the affected wires in the Wiremap section
to the open location.
If there are MULTIPLE faults:
1. If more than one type of fault is encountered, the tester will display "MULTI" and show the appropriate fault
icons for the corresponding wires in the Wiremap section
distance to the first fault encountered.
NOTE: Cable length is determined by the Velocity of Propagation (VoP) of the cable. Ensure the correct VoP is
entered for accurate length measurements. See VoP section for more detail.
6
VDV501-770-1390677ART Scout Pro Max Manual.indd 6-7
VDV501-770-1390677ART Scout Pro Max Manual.indd 6-7
,
,
,
to navigate to any test mode (Data, Voice,
8
9
10
11
and #3
to navigate between default wire types and press
5
6
,
,
,
to navigate to any test mode (Data, Voice, Coax)
8
9
10
11
to navigate to the bottom page of default wire types and press the
. Use the up and down arrow
12
. Use the up and down arrow
12
to edit. Use arrow button keys to
5
to save values.
, and the other end into the RJ45 port
15
,
,
,
to navigate to the Data Mode Icon
8
9
10
11
. The tester will also indicate the approximate distance
A
. The tester will also indicate the approximate
A
A
H
A.
Wiremap (will also display any faults detected)
B.
Individual wires of cable being tested
C.
Shield Indicator
D.
Length measurement (pairs)
E.
Test result
F.
Remote ID number
NOTE: ID number recognition is achieved through wire pair 3-6. If wires 3 and 6 are short circuited, or one
of them is open circuited, the ID number cannot be recognized.
G.
Wiring standard being tested (changeable in SETTINGS)
H.
Cable Type Indicator
I.
Cable Type Button (press "Soft Key" Button
J.
One-Time / Continuous Test Button (One-Time mode shown, press "Soft Key" Button
NOTE: in One-Time Test mode, press Enter Button
K.
Save Button (press "Soft Key" Button
on
1B
NOTE: Test + Map remote must be used for wire map testing.
and press
E1
RJ45 CROSSOVER:
RJ45 SHORT:
. The tester
A
B
C
I
J
K
to change)
5
to repeat test
12
)
7
WIRE MAP AND DISPLAY EXAMPLES
RJ45 MISWIRE:
RJ45 OPEN:
D
E
F
G
to change)
6
7
