ENGLISH
OPERATING INSTRUCTIONS
POWERING ON/OFF
Power ON: Press the Power Button
to turn the unit on.
3
Power OFF: Press the Power Button
for two seconds to turn the unit off.
3
Auto Power-OFF (APO): The Meter will automatically turn off after a period of inactivity in order to conserve
battery power. The time until auto power off depends on which mode the unit is in:
Test Mode: User-adjustable from 10 to 60 minutes (default is 20 minutes).
Tone Mode: User-Adjustable 5 to 60 minutes, or OFF.
In either mode, the screen will dim after 90 seconds of inactivity to conserve battery power.
"SOFT KEY" BUTTONS
,
,
,
4
5
6
7
Some modes will display up to four icons along the bottom of the LCD display. These icons correspond to
additional functionalities available in that mode. To select one of these functions, press the "Soft Key" button
directly beneath the icon.
HOME SCREEN
The Home Screen will appear upon powering on the tester. Icons representing all available modes will appear on
this screen. To select a mode, use the Arrow Buttons
press the Enter Button
. Press the Home Button
12
A
B
E1
E2
E5
E6
E
E9
E10
E1.
Data (RJ45) Wiremap / Testing / Length
E2.
Voice (RJ11/RJ12) Wiremap / Testing / Length
E3.
Coax Testing / Length
E4.
POTS (Plain-Old-Telephone-Service) Testing
E5.
POE (Power Over Ethernet) Testing
E6.
Analog Toning
4
VDV501-770-1390677ART Scout Pro Max Manual.indd 5
VDV501-770-1390677ART Scout Pro Max Manual.indd 5
,
,
,
to navigate to the desired mode's icon and
8
9
10
11
to return to this screen from any other screen.
14
C
D
A.
Current date
B.
Current time
E3
E4
C.
Currently Active Function/Screen
D.
Battery Status
E.
Mode Icons:
E7
E8
E11
E7.
Digital Toning
E8.
Hub Blink
E9.
Active Network Testing
E10.
Recall
E11.
Settings
OPERATING INSTRUCTIONS
SETTINGS
1. From the Home Screen, use the Arrow Buttons
the Enter Button
.
12
2. Use the Arrow Buttons
,
,
,
to navigate to the desired setting and press the Enter Button
8
9
10
11
3. Use the Arrow Buttons
,
,
,
to make adjustments. Press the Enter Button
8
9
10
11
4. Use the Page Up/Down button ("Soft Key" Button
DATE: Month/Day/Year
A.
UNITS: Feet (ft) or meters (m)
B.
A
TIME: Hours:Minutes
C.
BRIGHTNESS
D.
C
LANGUAGE: English,
E.
Spanish, French, or German
T568: Selectable between
E
F.
T568A and T568B
Page Up/Down Button
G.
(press "Soft Key" Button
to navigate)
6
DIM TIMER: ON or OFF
H.
APO (Auto Power-Off): Selectable between
I.
10, 20, 50, and 60 minutes
H
ABOUT: Hardware and software information
J.
(for reference only, cannot be changed)
J
FACTORY RESET: Deletes all saved data
K.
and reverts all settings back to factory defaults
Page Up/Down Button
L.
K
(press "Soft Key" Button
to navigate)
6
LANGUAGE SELECTION
The tester can display screens in English,
Spanish, French or German (default language
is English). It is strongly recommended that
you set the tester to the appropriate date, time,
units, wiring configuration, and language of
choice at this point, before proceeding:
1. Use the Arrow Buttons
,
,
,
to
8
9
10
11
navigate to the Settings Icon
and press
E11
the Enter Button
.
12
2. Use the Up
and Down
Arrow Buttons
8
9
to navigate to the LANGUAGE field
and
F
press the Enter Button
.
12
3. Use the Up
and Down
Arrow Buttons
8
9
to select the desired language and press the
Enter Button
.
12
4. Press the Home Button
to return to the
14
Home Screen.
,
,
,
to navigate to the Settings Icon
8
9
10
11
E11
when finished.
12
) to access page 1 and 2 of the Settings menu.
6
PAGE 1
G
PAGE 2
L
8/20/2024 6:44:25 PM
8/20/2024 6:44:25 PM
and press
.
12
B
D
F
I
5
