ENGLISH
DELETING SAVED TEST RESULTS
To Delete Individual Results:
1. From the Home Screen use the Arrow Buttons
2. Use the Up and Down Arrow Buttons
start delete process.
When prompted to "Confirm Delete" use either soft key
TO DELETE ALL RESULTS
1. From the Home Screen use the Arrow Buttons
2. Press soft key
to start the delete process. Press soft key
4
3. When prompted to "CONFIRM DELETE ALL" use either soft key
Loosen the screw in the battery cover
MAIN BATTERIES (3× AA, REQUIRE INSTALLATION BEFORE FIRST USE)
1. If replacing batteries, remove and recycle spent batteries.
2. Install three AA alkaline batteries
INTERNAL CLOCK BATTERY (CR2032, PRE-INSTALLED)
1. Using a flathead screwdriver, rotate Internal Clock Battery Cover
2. Pry out exhausted CR2032 battery
3. Install new CR2032 battery, noting proper polarity.
4. Replace cover and rotate back to the locked position until it clicks into place. Do not overtighten.
THEN: Replace main battery cover and tighten screw. Do not overtighten.
• VDV770-770 Replacement Self-Storing Test + MapTM ID Remote
• VDV999-770 Replacement Lead Set
• VDV770-129 Replacement Case
Turn instrument off and disconnect any cables. Clean the instrument by using a damp cloth.
Do not use abrasive cleaners or solvents.
Remove the batteries when instrument is not in use for a prolonged period of time. Do not expose to high
temperatures or humidity. After a period of storage in extreme conditions exceeding the limits mentioned in the
Specifications section, allow the instrument to return to normal operating conditions before using it.
See this product's page at www.kleintools.com for FCC compliance information.
Do not place equipment and its accessories in the trash. Items must be properly disposed of in
accordance with local regulations. Please see www.epa.gov/recycle for additional information.
18
VDV501-770-1390677ART Scout Pro Max Manual.indd 18
VDV501-770-1390677ART Scout Pro Max Manual.indd 18
OPERATING INSTRUCTIONS
8 9 10 11
to navigate to the desired test result and press the soft key
8 9
1
8 9 10 11
BATTERY INSTALLATION / REPLACEMENT
with #2 Phillips screwdriver and remove cover. THEN:
18
, noting proper polarity.
28
with a flathead screwdriver, using the pry slot next to the
30
REPLACEMENT PARTS
CLEANING
STORAGE
FCC & IC COMPLIANCE
Canada ICES-003 (B) / NMB-003 (B)
WARRANTY
www.kleintools.com/warranty
DISPOSAL / RECYCLE
to the Recall Icon and press the Enter Button
or
to confirm deletion.
4
to the Recall Icon and press the Enter Button
to prompt delete all.
3
or
to confirm deletion.
1
3
to the unlock position
29
12
to
4
12
to remove.
icon.
