3 If the run time of the descaling cartridge is exhaust-
ed, the steam switch flashes orange quickly and
constantly.
The descaling cartridge must be replaced with a
new one.
Illustration W
Note
In this mode, to protect against possible damage to the
device, steam operation is no longer possible. Steam
operation is therefore only possible again after the des-
caling cartridge has been successfully replaced, see
chapter Initial Start-Up
Inserting the decalcification cartridge
ATTENTION
Device damage
There is a risk of damage to the device if the used de-
calcification cartridge is re-used.
Work carefully in order to prevent mixing up the new and
old cartridge.
Note
When steaming for the first time after removing and re-
inserting the decalcification cartridge, the steam jet may
be weak or irregular, and individual drops of water may
be expelled. The device requires a short running-in pe-
riod in which the decalcification cartridge fills with water.
The steam volume that is expelled increases constantly
until the maximum steam volume has been reached af-
ter approx. 30-60 seconds.
Note
The water tank must be removed before changing the
descaling cartridge and inserted again after it has been
changed, see chapter Initial Start-Up
1. If the device is in steam mode, lightly press the
steam switch once to turn off the steam.
2. Pull the mains plug out of the socket.
Illustration S
3. Remove the decalcification cartridge.
4. Insert the new decalcification cartridge and press it
firmly into place.
Illustration D
Illustration E
5. Press the steam switch and insert the mains plug in-
to a socket.
Continue to hold the steam switch for 7 seconds.
6. After a successful reset, the steam switch flashes
green and then switches to heating mode.
The run time of the descaling cartridge starts again.
Illustration X
7. To bleed the descaling cartridge, press the steam
switch once lightly, it will take approx. 30-60 sec-
onds until a steady steam is emitted.
Care of accessories
(Accessories - depending on scope of delivery)
Note
The cloths are not suitable for the dryer.
Note
For optimum cleaning performance, we recommend
machine washing the cloths once before first use.
When washing, observe the notes on the washing tag.
Do not use any liquid softeners as this will affect the abil-
ity of the cloths to pick up dirt.
1. Wash the floor cleaning cloths and covers at a max.
temperature of 60 °C in the washing machine.
Troubleshooting guide
Malfunctions often have simple causes that you can
remedy yourself using the following overview. When in
doubt, or in the case of malfunctions not mentioned
here, please contact your authorised Customer Service.
WARNING
Risk of electric shock and burns
Trying to eliminate faults while the appliance is connect-
ed to the mains or has not yet cooled down is always
dangerous.
Remove the mains plug.
Allow the appliance to cool down.
No steam / little steam although there is sufficient
water in the reservoir
The decalcification cartridge has not been inserted or
has been inserted incorrectly.
 Fit the decalcification cartridge and/or check that the
decalcification cartridge sits tightly in the device and
press in again if necessary.
The decalcification cartridge has been removed when
filling with water and/or a new decalcification cartridge
has been fitted
 Always leave the decalcification cartridge in the de-
vice when topping up.
 Lightly press the steam switch once.
The full steam output is reached after approximately
30-60 seconds.
The steam switch flashes orange but the device still
functions correctly
Run time of the decalcification cartridge ends soon.
 Insert a new decalcification cartridge, see chapter
Replacing the decalcification cartridge.
No steam despite sufficient water in the reservoir,
and the steam switch flashes orange quickly and
constantly
Run time for the decalcification cartridge has expired
 Insert a new decalcification cartridge, see chapter
Replacing the decalcification cartridge.
 If a new descaling cartridge has already been insert-
ed and the error still occurs, it's likely that the RE-
SET function was not performed after restarting the
device.
After inserting the descaling cartridge, press the
steam switch, insert the mains plug and hold the
steam switch for 7 seconds, see chapter Inserting
the decalcification cartridge
After 5 minutes of continuous steaming, the steam
switches off automatically
The switch off prevents the pump from running dry if it is
not noticed that the water reservoir is empty.
 Check whether there is still enough water in the wa-
ter reservoir. Top up water if necessary.
 To start the steam operation, press the steam switch
lightly once.
Technical data
SC 1 Multi, SC 1 Multi Comfort, SC 1 Multi & Up
Electrical connection
Voltage
Phase
Frequency
Degree of protection
Protection class
English
V 220-240
~ 1
Hz 50-60
IPX4
I
