ronment. However, these components are required for
the correct operation of the device. Devices marked by
this symbol are not allowed to be disposed of together
with the household rubbish.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.de/REACH
Accessories and spare parts
Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.
Scope of delivery
The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.
Warranty
The warranty conditions issued by our relevant sales
company apply in all countries. We shall remedy possi-
ble malfunctions on your appliance within the warranty
period free of cost, provided that a material or manufac-
turing flaw is the cause. In a warranty case, please con-
tact your dealer (with the purchase receipt) or the next
authorised customer service site.
(See overleaf for the address)
Further warranty information (if available) can be found
in the service area of your local Kärcher website under
"Downloads".
Safety devices
CAUTION
Missing or modified safety devices
Safety devices are provided for your own protection.
Never modify or bypass safety devices.
Symbols on the device
(according to type of appliance)
Risk of burns, surface of appli-
ance becomes hot during opera-
tion
Risk of scalding from steam
Read the operating instructions
USE WATER ONLY Only fill water without additives
into the water reservoir
Safety valve
In the case of excessively high pressure in the event of
a fault, a safety valve relieves the pressure into the at-
mosphere.
The fuse prevents the device from overheating. If the
device overheats, the fuse disconnects the device from
the power supply.
Before re-commissioning the device, contact the re-
sponsible KÄRCHER Customer Service.
Fuse
Device description
The maximum amount of equipment is described in
these operating instructions. Depending on the model,
there are differences in the scope of delivery (see pack-
aging).
For the illustrations, refer to the graphics page.
Illustration A
Steam nozzle
1
Accessories unlocking button
2
LED display light with steam switch
3
Handle / extension tube connection
4
Detachable handle with unlocking button
5
Mains connection cable with mains plug and hook-
6
and-loop cable tie
Decalcification cartridge
7
Water reservoir
8
** Extension hose with connection adapter and
9
steam gun
Manual nozzle
10
Cover for manual nozzle (1 x)
11
** Extension tubes (2 x)
12
Unlocking button
13
** Floor nozzle
14
Hook and loop fastener
15
** Floor cleaning cloth
16
** optional
Initial Start-Up
ATTENTION
Device damage due to calcification
Without a descaling cartridge, limescale can build up
and damage the device, so the device cannot be oper-
ated without a descaling cartridge.
Ensure that the descaling cartridge is correctly inserted
in the device before operation.
1. Mount the handle on the device.
Illustration B
2. Hold the water reservoir at the side with your hand
and pull it downwards.
Illustration C
3. Remove the descaling cartridge from the packaging.
Illustration D
Note
When using the descaling cartridge, make sure that the
KÄRCHER lettering can be read correctly in the direc-
tion of view.
4. Inserting the decalcification cartridge:
Place the descaling cartridge at a slight angle un-
der the two upper plastic ribs.
After positioning the descaling cartridge under
the plastic ribs, press it down until you hear it click
into place.
Illustration E
English
11
