Symbols
The symbols and their meaning in the manual or on the product label are indicated below.
Generic danger
Important safety information. Indicates operations and situations in which the personnel involved
must pay close attention.
Dangerous voltage risk
Indicates operations and situations in which the personnel involved must pay close attention to
dangerous voltages.
Useful information
Indicates useful information for the installation.
Refer to the Installation and use instructions
Indicates the obligation to refer to the manual or original document, which must be available for
future use and must not be damaged in any way.
Protective earth connection point.
Indicates the admissible temperature range.
Alternating current (AC)
Direct current (DC)
Symbol for the product disposal according to the WEEE directive.
2
Product description
The B70/1DC controller is a unit for the SENSORED control, with a high resolution encoder, of a ROGER brushless motor
for automated sliding gates.
Ensure that the parameter
may not function properly.
ROGER TECHNOLOGY cannot be held responsible for any damage or injury due to improper use or any use other than
the intended usage indicated in this manual.
recommend installing F4ES or F4S series photocells.
For further information, refer to the installation manual of the BH30 or BM30 automation system.
3
Updates of version P2.35
1. Fine-tuned the stroke programming procedure.
2. Optimised the management of the parameters when they are changed by B74/BCONNECT.
3. Improved the management criterion for battery operation; adjusted the battery voltage thresholds (par.
54
is set correctly. If this parameter is not set correctly, the automation system
) combined with the use
