EquIPmEnT FIG.1-2
1 Machine head
2 Base frame
3 Legs
4 Tub
5 Alu. table
6 Angled stop
7 Stop rails
8 Guide rails
9 Cutting disc protection
10 Diamond cutting-disc
11 Handle
12 Star knob screw for angle adjustment
13 Pin for transport lock
14 Cooling water pump
15 Hose
16 Motor
17 ON/OFF switch
18 Angle scale
19 Table extension
20 Saw blade protection
