country, the generally recognized technical rules of en-
gagement for the operation of the machine must also be
observed.
GEnERAL InSTRucTIOnS
• After removing the packing, check the components for
possible transport damage. In case of complaints, ple-
ase inform the delivery agent immediately. Subsequent
complaints will not be entertained.
• Check the delivery to ensure that it is complete.
• Familiarize yourself with the machine with the help
of the operating instructions manual before using it.
• Use only original parts for accessories as well as con-
sumables and spare parts. Spare parts can be obtained
from your scheppach retailer.
• Please quote our article numbers as well as type and
production year in all your orders.
fs 850
Delivery scope
Counter torque wrench
Technical data
Production dimensions 1250 x 530 x 1090 mm
L x w x H
cutting table
Diamond cutting disc D
Hole D
water filling quantity
approx.
Speed
weight
Section data
max. cutting length
max. diagonal cutting
length
max 90° cutting height
max. 45° cutting
height
Drive
motor
Power intake
motor speed
Insulating material
class
Protection type
Technical changes reserved!
nOISE cHARAcTERISTIc VALuES
Noise at the workplace can exceed 85 dB (A). In this
case, noise protection measures are necessary for the
user (wear hearing protection!).
nOISE OuTPuT LEVEL In DB
LWA idling / processing of LWA = 108/111 dB (A)
Noise pressure level at workplace in dB
LPA idling / processing of LPA = 95/98 dB (A) according
to DIN EN ISO 3744; EN ISO 11201
Tile-cutter
Tub
Cooling water pump
Angled stop
Table extension
4 legs
Handle
14mm wrench
680 x 465 mm
180 mm
22,2 mm
18,0 l
5800 1/min
40, 0 kg
850 mm
640 x 640 mm
40 mm
14 mm
230 V/50 Hz
1250 W (S3 20%)
2950 1/min
B
IP54
