this operating instructions manual, all warranty claims
will become null and void. We do not accept any lia-
bility for consequential damages.
• Check the product for damage before each use! If you
detect a damage, do not connect the product to the
mains power supply!
• After actuating the orange Reset button, the device is
ready for operation. Before operation, please test the
triggering with the help of the Test button (as descri-
bed in "Operation").
• Insert the leakage current circuit-breaker into the so-
cket.
• Press the orange Reset button.
• A red symbol is displayed in the window indicating
operational readiness.
• Press the red Test button. This action simulates a
leakage current.
• If the machine is working properly, the circuit-breaker
will disconnect the load from the mains. This is dis-
played in the window through the disappearance of
the red symbol.
• Protection of man and animal is effective only if the
machine works properly.
• The Reset button must be pressed a second time for
operation.
• The load can now be inserted.
Technical data:
Triggering leakage current: < 30 mA
Power supply: 230V~/50Hz
Load capacity: 16A (3680W)
Number of pins: 2-pin wired
Preliminary fuse: 16 A
Protection type: IP54
Dimensions: 126x50x88mm
uSE AccORDInG TO mAnuFAcTuRER'S InSTRucTIOnS!
The portable leakage current circuit-breaker is designed
for wet grinding machines and similar electrical loads in
the household.
It is simply connected between the mains power supply
and the load, and therefore offers optimum protection
against physical contact with live components and sud-
den restart of the machine after restoration of power.
• Always operate the machine with the provided leakage
current circuit-breaker installed.
