Part 2- Mechanical Installation
2.1 Control Board Overview
X-motor Y-motor Z-motor Spindle
Handwheel
Air Pump
Laser
USB
24V 5A
Power
Offline E-stop Z-probe X-limit Y-limit Z-limit Power
Controller Switch Switch Switch Switch
