Part 2- Mechanical Installation
STEP 6 Installing E-stop Switch
What you will need
XZ Axis Assembly E-stop Switch with Cable
2 29
1. Separate the emergency stop switch into two parts by removing the square gasket and black plastic nut.
2. Place the rubber gasket and button on the outside.
3. Pass the wire through the X-axis plate hole, the iron square gasket and the black plastic nut in turn, then tighten the
black plastic nut on the inside to complete the installation.
