The direction changed may only be
performed­in­standstill­mode.
Torque setting
you­can­preset­the­maximum­torque­by­
rotating­the­torque­adjustment­ring­(2).­
20+1­torque­levels­are­provided.­
1.­ Turn­the­adjusting­ring­(2)­to­select­the­
desired torque:
­ Step­1­-->­­
­ Step­ -->­
Screws:­­
Drilling:­­
2.­ Start­with­a­lower­torque­step­and­in-
crease according to requirement.
­ Torque­adjustment­should­only­be­
performed­in­standstill­mode.
­ Reaching­the­preset­torque­limit­pro-
duces­a­noticeable­rasping­sound.­
This­sound­is­caused­by­the­slip­
clutch.
Tool change
The­automatic­spindle­lock­enables­the­tool­
to be changed even when the motor is at a
standstill.
1.­ Rotate­the­keyless­chuck­(1)­towards­
­until­the­drill­chuck­aperture­
RELEASE
(11)­is­large­enough­to­accommodate­
the tool.
2.­ Push­the­tool­as­far­as­possible­into­the­
keyless­chuck­(1).
3. Turn the keyless chuck towards
order­to­clamp­the­tool.
4. To remove the tool again, rotate the
keyless­chuck­(1)­and­pull­out­the­tool.
lowest­torque,­
highest­torque.
Steps­1­-­20
Step­
GRIP
Removing­the­keyless­
chuck
To­use­the­bit­holder­(18),­you­must­remove­
the­keyless­chuck­(1).­
1.­ Hold­the­keyless­chuck­(1)­tightly­from­
the­front.­Pull­or­push­the­drill­chuck­
ring­(19)­in­the­direction­of­the­keyless­
chuck­(1).­
2.­ This­unlocks­the­keyless­chuck­(1)­and­it­
can­be­pulled­off­from­the­front.
3.­ In­order­to­put­the­keyless­chuck­(1)­
back­in­position,­pull­the­drill­chuck­
ring­(19)­in­the­direction­of­the­keyless­
chuck.­Push­the­keyless­chuck­(1)­on­as­
far as it will go.
When attaching the keyless chuck,
a 25 mm bit may remain in the bit
holder­(18).
­ If­the­keyless­chuck­(1)­does­not­
engage automatically, turn the drill
chuck­ring­(19).
Using the bit holder
After­removing­the­keyless­chuck­(1)­you­
can­use­the­bit­holder­(18).
1.­ Insert­a­suitable­6-point­bit­in­the­bit­
holder­(18).­
Because­of­the­6-point­bit­holder,­it­
may be that you need to rotate the bit
slightly.
2. Slide the bit right into the bit holder
(18).­
in 3. To remove the bit, remove the bit from
the­bit­holder­(18).
