Hydraulic Unit - Te Connectivity At-66 Bedienungsanleitung

528050-6 / 528050-5
6.3

Hydraulic unit

7
8
5
1
Item No. Description
1 Connection cable to crimp machine
2 Hydraulic hose
3 Hydraulic hose
4.0 Power line connecting cable (with CEE plug and phase changing switch) (EU-Version)
4.1 Power line connecting cable (with HBL2811-Plug without phase changing switch) (US-Version)
5 Oil level viewer
6 Electric main switch
7 Oil filter
8 Vent cap of the hydraulic unit
Fig. 6.06
