528050-6 / 528050-5
6

Technical Description

6.1

Front View Hydraulic Crimp Machine AT-66

8
7
Item No. Description
1 Eyebolt
2 Key switch button
3 Release Button
4 U-DIE-ADAPTER with safety guard for AT-66 (Adapter sample, not included in the scope
of the delivery. Available adapters see chapter 8.1)
5 Hydraulic unit
6 Foot Switch
7 Operator Display
8 Hydraulic crimp machine AT-66
Seite / Page / Página 89 / 232
412-18954 Rev. F
1
2
3
4
Fig. 6.01
6
ECOC: EGC0 ; LOC: AI
5
Fig. 6.02
