Production Cycle With "P1 - Te Connectivity At-66 Bedienungsanleitung

528050-6 / 528050-5
1. Ensure that the mains and hydraulic supply is correctly connected.
2. Ensure that the crimp machine is calibrated and the oil system has been bled.
3. Ensure that the tooling adapter is fitted with the correct die set and safety guard.
4. Start the hydraulic Crimp Machine AT-66 with the main control switch.
5. Choose a program no. according to chapter 10.1.3 and turn the key operated switch for the normal
operation to the left into the
The display (Fig. 10.02) is showing the chosen program no., the quantity of the completed crimp cycles
and the program type ("P1", "P2", "P3").

Production Cycle with "P1"

11.1
DANGER!
 Due to the risk of hand or finger injury, never try to reach into the machine before
having assured that the hydraulic unit is disconnected from the power supply.
 Disconnect the hydraulic unit from the power supply by operating the main control
switch and pull out the power plug, before mounting or changing the safety guard,
die adapter and die set!
CAUTION!
 Every machine operator, who is working with the machine, must read and
understand the operating instruction. During the work on or with the machine the
operator has to follow the guidelines of the operating instruction!
 The crimp machine is only allowed to be used with mounted die sets, die adapter
and the suitable safety guard. Pay attention to the correct assignment of adapter to
safety guard!
 The hydraulic Crimp Machine AT-66 may only be set up and operated in perfect
technical condition, observing all the safety regulations and considering any
possible dangers.
 Assure free access to the operating elements of the machine, especially the foot
switch, the release button and the main control switch. In the case of imminent
danger immediately press the release button. The release button must be within the
direct reach of the operator. It must not be covered.
 Before commissioning the machine, it is always important to check whether all
safety devices, especially the safety guards and die adapter, are installed and are
functioning correctly.
 Check the release button before starting the work on the crimp machine.
 When working with the hydraulic Crimp Machine AT-66, do not wear loose clothing,
jewellery or long, loose hair that can get caught in the hydraulic Crimp Machine
AT-66.
 Work with caution.
 In cases of a machine malfunction, production must be stopped and the
malfunction must be fixed before continuing work with the machine.
 Only one person is allowed to work on or with the machine.
 Only trained personal are allowed to work on or with the machine.
1. Place the crimp terminal in position in the die profile.
2. Place the wire/cable in position for crimping.
3. Press the foot switch to start the crimp process and keep pressed until the machine head starts to
return to the top.
4. Remove crimped terminal.
"Production
Mode".
