Anhang B
Branch Circuit Protection: Type E Self Protected Manual Motor Controllers for Drive
series inverters F5–D and F6-D.
Listed (NKJH) Type E Self Protected Manual Motor Controllers. Type and manufacturer and
electrical ratings as specified below:
240V devices:
Inverter
model
F5/F6
07
07
09
09
10
10
12
12
480V devices:
Inverter
model
F5/F6
07
09
10
12
13
14
(#) all Drives series which use a Self Protected Motor Controller rated 480Y/277V are
Drive input
rating
Manual Motor Controller Type
240V/ 1ph
PKZMO–16E, Eaton Industries
240V/ 3ph
PKZMO–10E, Eaton Industries
240V/ 1ph
PKZMO–20E, Eaton Industries
240V/ 3ph
PKZMO–16E, Eaton Industries
240V/ 1ph
PKZMO–32E, Eaton Industries
240V/ 3ph
PKZMO–16E, Eaton Industries
240V/ 1ph
PKZMO–40E, Eaton Industries
240V/ 3ph
PKZMO–25E, Eaton Industries
Drive input
rating (#)
Manual Motor Controller Type
480V/ 3ph
PKZMO–10E, Eaton Industries
480V/ 3ph
PKZMO–10E, Eaton Industries
480V/ 3ph
PKZMO–12E, Eaton Industries
480V/ 3ph
PKZM4–16E, Eaton Industries
480V/ 3ph
PKZM4–25E, Eaton Industries
480V/ 3ph
PKZM4–25E, Eaton Industries
suitable for 480y/277V sources only.
Self Protected
and manufacturer
Self Protected
and manufacturer
Self Protected
Manual Motor
Controller rating
230 V/ 1ph, 2 hp
230V/ 3ph, 3 hp
230 V/ 1ph, 3 hp
230V/ 3ph, 5 hp
230 V/ 1ph, 5 hp
230V/ 3ph, 5 hp
230 V/ 1ph, 7,5 hp
230V/ 3ph, 7,5 hp
Self Protected
Manual Motor
Controller rating
480Y/277V, 7,5 hp
480Y/277V, 7,5 hp
480Y/277V, 7,5 hp
480Y/277V, 10 hp
480Y/277V, 15 hp
480Y/277V, 15 hp
D - 43
