Important: If the rotating speed slows down continuously during operation or the
motor stalls, there may be too much food in the grinding cup, and/or there are
too many too hard ingredients blocking the knives. Switch off the appliance at
the selection dial and power switch and unplug. Remove the grinding system from
the motor base. Then remove any obstacles. If required, take out some food and
process your food in smaller portions.
Tip: For loosening the ingredients from the knives or the inner walls of the grinding
cup, it may be sufficient to shake the grinding cup or hit the grinding cup slightly
against your palm. For this, always remove the grinding cup from the motor base.
However, do not strike the grinding cup against any hard or sharp-edged
objects! Depending on the desired result, you may try to operate the motor in
pulses by turning the selection dial slowly to and fro several times.
Note
The appliance will process your food in some seconds. It is better to intermedia-
tely check the consistency of your food (after processing for a few seconds) than
to over-process your food.
Note
If the motor does not start, when selecting a speed level, check whether the con-
nections of the blade assembly to the grinding cup and the motor base are suffi-
ciently tight. Always switch off the appliance, before checking the connections.
10. Switch the power switch at the rear of the motor base to the ON position
("I"). Then, turn the selection dial to the desired speed level (see: 'Tips for Best
Results'). The motor should start agitating at once. If not, see: 'Solving Problems'.
11. After grinding is done, turn the selection dial to the "OFF" position, switch off
the appliance at the power switch, and unplug. Then disassemble the appliance
(see below: 'Disassembling the Grinding System') for getting out your food.
Important: Do not leave the appliance unattended when it is connected to the
power supply.
Disassembling the Grinding System
12. Ensure that the selection dial is turned to "OFF" and the power switch is switched
off ("O"). Unplug the appliance.
108
Do not turn the processing system by the grinding cup. Always
CAUTION:
grasp the blade assembly. Otherwise, the connection of the grinding cup and
blade assembly cold get loose and your food will fall out.
Do not strike the grinding cup against any hard or sharp-edged object for loo-
sening the food from the blade assembly. However, you may hit the grinding cup
slightly against your palm.
13. Grasp the blade assembly by the collar and turn it counter-clockwise to unscrew
it from the motor base. Then lift the grinding system from the motor base.
14. Hold the grinding system with the blade assembly facing upwards and hit the
grinding cup slightly with your palm or shake the powder from the blade assem-
bly into the grinding cup.
Tip: For keeping your workspace clean, we recommend to open the grinding sys-
tem over a large dish.
15. Turn the blade assembly counter-clockwise for removing the blade assembly.
16. Remove your food. If you do not wish to process another portion, clean the used
parts (see: 'Care and Cleaning').
SOLVING PROBLEMS
Many problems occurring during operation may be solved easily by observing the
hints, given in 'Properties of Your New Multi Juicer', 'Tips for Best Results' and 'Ope-
ration'. Additionally, you will find solutions in the following table.
Problem Reason The Solution
The display stays The appliance is not Check, if the power plug is inserted in an appropriate wall power
dark and the motor live. outlet and the used power outlet is live (connect a lamp).
does not move, alt-
The power switch at First turn the selection dial to "OFF". Then switch the power
hough a speed is
the rear of the appli- switch at the rear of the appliance to position "I". Try again.
selected.
ance is switched to
"O" (off).
The automatic shut- After 20 minutes or more in operational mode (switched on
off is active with a speed selected), the automatic shut-off is activated (see:
'Automatic Shut-Off'). Simply select another speed for re-acti-
vating the appliance.
