BEFORE FIRST USE
DO NOT let children play with the appliance or any part of
WARNING:
it! The knives of the juicing sieve and blade assemblies are very sharp! Always
use special care when handling these parts. Only hold these parts by the rim.
Always unplug the appliance before cleaning or moving it, before assembling or
disassembling any parts, and when the appliance is not in use. Do not place or
immerse the motor base or power cord in water or other liquids or spill any liquids
on the exterior of the appliance. Do not use any abrasive or corrosive cleaners for
cleaning to avoid damage to the surfaces. Do not place the motor base in an
automatic dishwasher.
1. Unpack the appliance and all parts and accessories carefully. Handle the jui-
cing sieve and blade assemblies with special care, because the integrated kni-
ves are very sharp. Check that no parts are damaged or missing (see: 'Knowing
Your New Multi Juicer').
2. Carefully remove all packaging, shipping materials, stickers, and promotional
materials. However, DO NOT remove the model label or warning labels.
3. Before first use and after an elongated period of storage, clean all parts of the
appliance (see: 'Care and Cleaning'). If required, take the power cord out of
the cord storage in the baseplate of the motor base. Push the power cord into
the guiding groove at the rear part of the baseplate.
4. Position the motor base with the display facing towards you on the designated
working place near an appropriate wall power outlet. The locking arm must be
lowered to the horizontal open position.
For operation, always unwind the power cord completely
WARNING:
(approx. 110 cm) to avoid overheating and risk of fire and electric shock!
Important: When operating the appliance for the first time, there may be a slight
burnt smell from the motor. There is no need for concern. However, if the problem
persists even after repeated use, get in contact with an authorized service centre.
SELECTING AND MOUNTING THE APPROPRIATE PRO-
CESSING SYSTEM
The Multi Juicer is a very flexible tool for processing a wide variety of foodstuffs in
different ways. Due to the outstanding range of alternatives, the first step of getting
the desired consistency of your food is, selecting the best suited processing system:
juicer, mixer or grinder (see also: 'Tips for Best Results').
94
SELECTING THE OPTIMUM PROCESSING SYSTEM
• The juicing system is designed for preparing juices. Additionally, you may use
the capabilities of this system for breaking and cutting tough fibres of fruit and
vegetables that would be wound around the knives, when processed by a food
processor.
Important: It is not possible to combine the parts of the juicing system with the
accessories for mixing and grinding described below.
Mixing and Grinding Systems
• The mixing system is suited for stirring, blending, beating, and whisking of larger
amounts of liquids and runny food (up to 1.5 litres). The ingredients will be chop-
ped more or less, depending on the amount and consistency of your food, the
processing time, and your speed selection.
• The grinding system is dedicated for grinding solid and dry ingredients, that will
not give off too much oils and juices, making the result lumpy and sticky. Use the
grinding system for foodstuffs that will reach a powdery or granulated consistency,
when ground.
Tip: You may combine the various blade assemblies and glass containers (mixing
jugs, grinding cup) according to the intended tasks. For example:
• If you wish to grind dry ingredients (e.g. nuts, almonds, cereals) and mix the
results with runny or liquid ingredients (e.g. yoghurt with further flavours), you may
use the mixing jug with the grinding blades and off with grinding the dry ingre-
dients. Thereafter, simply add the yoghurt and further ingredients and mix for get-
ting your flavoured yoghurt mix. Process the solid ingredients in pulses and select
speed level 1 for mixing the ingredients.
Note
When combining the various glass containers and blade assemblies, keep in mind
that the best results will be achieved in most cases, when using the glass contai-
ners with the dedicated blade assembly. In some cases, adapting the processing
time or speed level may be adequate too. Additionally, you may try operation in
pulses.
ASSEMBLING THE JUICING SYSTEM
1. Place the pulp container tightly against the left side of the motor base. The pulp
container protrusion at the baseplate of the motor base must slide completely into
the groove at the bottom of the pulp container.
95
