EN
WARNING! Make sure that the power cord plug is disconnected from the power supply when
assembling the vacuum cleaner
1. Ensure the power cord is disconnected from the power socket (Fig. 1).
2. Loosen the container clamps (Fig. 2).
3. Lift the top lid off the container (Fig. 3).
4. Remove all accessories from the container (Fig. 4).
5. Put the lid on the container, having previously mounted the appropriate
filter (for wet washing or for collecting water: put the sponge of the
water filter on the protruding part of the vacuum cleaner (Photo 1) or
mount the HEPA filter (Photo 2) and put a paper bag on the internal air
inlet (Photo 3) for dry vacuuming; then close the clamps on both sides
of the container (Fig. 5).
6. Insert the suction hose into the suction
inlet and then the washing liquid pipe into
the pump outlet. Insert them from the
right side and tighten (Fig. 6).
7. mount the washing liquid container by
screwing the cap to the right, connect
the tube from the liquid container to the
pump inlet (Fig. 7).
8. Connect the aluminium pipe with the
handle and insert the rubber pipe into the handle (Fig. 8).
9. Connect the two aluminium tubes, as shown here (Fig. 9).
10. Connect the washing nozzle to the aluminium tube, insert the rubber tube into the appropriate
connector (Fig. 10).
PAIRING THE REMOTE CONTROL WITH THE VACUUM CLEANER
1. Ensure the connection between the plug and the power source.
2. Press the power switch, the light on the panel switches on (Fig. 2).
3. Press the suction mode switch and the spray switch on the top lid panel simultaneously; the indi-
cator will light up (Fig. 3).
4. Press one of the buttons on the remote control handle in suction or spray mode, the indicator light
on the main panel will flash once and return to normal signalling the remote control pairing process
as completed (Fig. 4).
CAUTION! Before using the vacuum cleaner, please pair the remote control module with the
vacuum cleaner!
40
Photo 2
Photo 1
Photo 3
