Structure
5
Structure
Version without integrated solenoid valve
2
1
16
Fig. 3: Version without integrated solenoid valve
The compressed air must be switched on and off via an (external) 3/2 way compressed-air
solenoid valve provided by the customer.
Version with integrated solenoid valve
Fig. 4: Version with integrated solenoid valve
Compressed-air solenoid valve
1
The metering pump is controlled with an integrated 3/2-way solenoid control valve
The pressure connection
417101420 Rev. 7-03.2024
3
7
8
9
4
5
6
14
13
15
1
is on the control block.
2
Pump head
1
Delivery valve
2
Pressure-side hose connection
3
10
Membranes
4
Intermediate plate
5
11
Return spring
6
12
Piston
7
Compressed air connection
8
Valve block
9
Vent lever
10
Manual switch
11
Stroke control knob
12
Membrane breakage drain
13
Venting outlet
14
Suction-side hose connection
15
Suction valve
16
2
Compressed air connection
2
26
.
1
