Crivit VB-5626 Bedienungsanleitung Seite 41

Product/parts
Vibration board (1)
Expansion bands (8)
Case (4)
Remote control (dial) (3) VB-5626-CL
Delta-Sport Handelskontor GmbH
hereby declares that this product
complies with the basic requirements as well as
other relevant statutory provisions.
2014/53/EU – RED Directive
2006/42/EC – Machinery Directive
2011/65/EU – RoHS Directive
UK Conformity Assessed
Date of manufacture (month/year):
08/2022
This symbol identifies the vibration board
as a protection class 1 device.
Device class: H (for use in private households)
Tested in accordance with:
DIN EN ISO 20957-1, DIN 32935: 2018-A
Expander bands strength chart
Max. stretch length (in cm)
approx.
Force (N) approx.
The tolerance range for the force is approx. 20% (+/-).
The expander bands must
not be extended beyond
max.
the maximum stretch
185 cm
length!
Class H:
emission sound pressure level
L (1m) = 46.0dB(A)
pA
Version number
VB-5626
VB-5626-E
VB-5626-RC
185
65
Sound power level
L = 58.6dB(A)
WA
Sound pressure level measurement uncertainty
K = 1.4dB
pA
Sound pressure level measurement uncertainty
K = 1.4dB
WA
Vibration values:
Acceleration of the hand-arm system a
30.88m/s² (Fig. B/position C and position D)
Acceleration seated position A (Fig. B/position A)
a = 8.78m/s²
wz
Acceleration standing position B (Fig. B/position B)
a = 18.04m/s²
wz
Intended use
This product was designed as a fitness and
massage device for private use and is not suitable
for medical or commercial purposes. The product
is suitable for indoor use and is designed for use
by one person who has a maximum body weight
of 130kg.
Safety information
Risk of electric shock!
Faulty electrical installation or ex-
cessive mains voltage can lead to
electric shocks. Connect the product
to an easily accessible socket only,
so that you can quickly disconnect it
in the event of a fault.
• Only connect the product to a
properly installed, earthed wall
socket and only if the mains voltage
of the socket corresponds with the
specification on the type label.
• Do not operate the product if it is
visibly damaged or if the power
cable or mains plug is faulty.
=
hv
GB/IE 43
