3.7.3

Dimensions

Designation
Height
Width
Depth with cover (standard)
Installation depth DTI
Weight
Installation attitude
Unit construction
Tab. 11: Dimensions and weight model DTI / DTS 6201
Designation
Height
Width
Depth with cover (standard)
Installation depth DTI
Weight
Installation attitude
Unit construction
Tab. 12: Dimensions and weight model DTI / DTS 6301
3.7.4

Other unit data

Designation
Anti-corrosion protection
Housing protection type (according to EN 60529)
Operating Manual | Attachment and Installation Cooling Units | Multi Controller (MC) – 400 V, 2~ | 086100116
Unit
mm
mm
mm
mm
kg
—
—
Option: With stainless-steel cover
Unit
mm
mm
mm
mm
kg
—
—
Option: With stainless-steel cover
Standard: Galvanized, electrostatically powder-
coated (200°C)
Variant: Stainless-steel cover (material 1.4301, grounded)
When used as intended:
• IP 55 internal – against the switch cabinet.
• IP 24 internal – against the environment.
Model DTI / DTS 6201
DTI: 1537
DTS: 1540
485
218
60
DTI: 58
DTS: 61
Vertical
Standard: Steel sheet
Model DTI / DTS 6301
DTI: 1537
DTS: 1540
485
218
60
DTI: 59
DTS: 62
Vertical
Standard: Steel sheet
