Description of controls
The front panel
76
All the commands and controls for the hob and oven
are on the front panel.
THE CONTROL PANEL
DESCRIPTION OF HOB BURNER KNOBS
The flame is lit by simultaneously pressing and
turning the knob anticlockwise to the high flame
symbol
.
To regulate the flow of the flame, turn the knob to
between the maximum
Turn off the burner by returning the knob to the
position.
LAYOUT OF BURNERS – Description of symbols
REAR LEFT
CENTRE FRONT
FRONT LEFT
and minimum
settings.
REAR RIGHT
CENTRE REAR
FRONT RIGHT
