Belegung des Anschluss-Stecker Standard I/O (X1)
R
o
b
a
c
a t
T
C
Not assigned
GND
GND
GND
HIGH - Quick Stop
LOW - Quick Stop
HIGH - Cleaning Start
LOW - Cleaning Start
Supply Voltage
Ready
Supply Voltage
Fluid Level Control
Supply Voltage
Cleaning Error
R
Spray In
S
Wire Cutter
T
GND
