Fronius OPT/i TIG 2nd SpeedNet Installationsanleitung Seite 21

4
1
Disconnect the 8-pin plug from PC board NT242
If present, reinstall option before the PC board NT242:
Fit the PC board holder
6
Insert PC board
7
Fasten PC board with brass spacer
8
9
2
Connect the 16-pin plug to PC board NT601;
Connect the 4-pin Microfit plug to PC board
NT601
5
Connect the 8-pin plug from the new cable
harness to PC board NT242;
Connect the 8-pin plug you previously discon-
nected to the new cable harness
10
1
Connect the 4-pin plug from the new cable
harness to PC board NT601;
Connect the remaining 4-pin cables together
2
1
2
1
