In order to ensure always a sufficient clearance between FixPack and plough
during the turnover operation the front pin must be fitted as far as possible to the
rear in front of the guiding stop (32).
Warning: A changing of the working depth requires also a correction with the
adjustment device (30) of the integrated packer FixPack!

4.5 Cutting bar

The crumbling effect of the roller (9) will be
aided by the cutting bar (25). The cutting
bar moves soil into the roller, due to that
the soil will be crumbled and mixed more
intensively. With the screw (26) the volume
of soil which will be moved into the roller
will be altered.
