Content
Set content
Preface
Assembly in 10 steps
3 Installing electronics
5 Filling oil
6 Power connection batteries
8 Programming zero point + air suspension mode (when installed)
Cylinders & technical data
›
Set content
1 pump
2 four cylinders
3 control panel
4 main unit
5 three electric cables:
a) cable with 9-pole plug
b) cable with 4-pole plug
c) cable with 6-pole plug
76
Page 76
Page 77
Page 78
Page 79
Page 80
Page 81
Page 82
Page 82
Page 82
Page 83
Page 84
Page 85
Page 86
Page 87
Page 88
Page 88
Page 88
Page 89
Page 90
Page 94
6 power fuse incl. holder for battery
7 connecting nipples for inside the cylinders (8
stops/10 nipples/1 T-piece)
8 end user manual
9 order form for the hydraulic hoses
›
Preface
Products must be 100% user friendly and reliable. That is the strategic vision at E&P Hydraulics, the
designer of this levelling system. This philosophy does not only apply to customers. The mechanics
installing the system at the dealers, are also very important to us. Our product greatly depends on a
proper, professional installation. That is the reason why E&P do all they can do to support the people
who must install the system. This assembly manual is part of this policy. In 10 steps we will explain as
simply as possible how this system can be installed as properly and efficiently as possible.
However, this does not mean that installing the E&P Levelling System is an easy job. Installing this
system requires a high level of skill. After all, we are dealing with equipment that must be able to
withstand huge forces, something that is often underrated by people with insufficient technical training.
If the installation is not performed correctly, serious damages could result in a short time, and even
personal injury. Therefore, this system may only be installed by professional mechanics with sufficient
practical experience and a thorough relevant technical training. At all times, mechanics will bear sole
responsibility for the assembly of the system.
This document is based on hundreds of test hours as well as hundreds of successful installations.
If you follow this manual step-by-step, you will see what a wonderful as well as user friendly quality
product the E&P Levelling System is. However, there will always be aspects that can be improved. If
you have any suggestions, remarks or questions concerning this manual or the product, please do not
hesitate to contact us.
On behalf of E&P Hydraulics
Eric Klinkenberg & Pierre Blom
