1. Electrical initial setting
Pulley feed gear
Screwdriver
Tilt mark (*1)
END SENSOR
Casecon
drive gear
Drive angle of
cassette housing
PARTS WHICH NEED PARTICULAR CARE
When installing the mechanism chassis on the PWB unit,
take care so as to prevent deformation due to contact of
mechanism chassis with REC TIP SW.
AE CONNECTOR
AC CONNECTOR
START SENSOR
AL CONNECTOR
