To check the Bowden cable setting:
1. Start the engine (see chapter 6.7 "Starting
the engine (32 - 37)", page 40).
2. Put into gear (see chapter 7.1 "Starting clear-
ing (40 - 42)", page 41).
3. Slowly push the right handle (14/1) down-
wards (14/a) until a slight resistance is felt.
The pressure point of the clutch has been de-
termined.
4. If the travel drive is not switched on: Repeat
the previous steps.
5. If adjusting the Bowden cable is not success-
ful: Contact one of the manufacturer's service
centres.
5.6 Mounting the rod for the gear selector
lever (15, 16)
1. Attach the rod (15/1) at the bottom into the
gear shift mount (16/2).
2. Attach the rod on the top of the gear selector
lever (16/3) in the mount.
3. Secure the rod at the top and bottom with
washers and cotter pins.
5.7 Installing the flexible shaft for the snow
discharge spout (17, 18)
1. At the snow discharge spout:
■
Insert pin (17/1) of one end of flexible
shaft (17/2) into auger (17/3) as far as it
will go (17/a).
■
Tighten knurled nut (17/4) by hand.
2. Under the operating panel:
■
Insert pin of the other end of flexible shaft
(18/1) from below into crank (18/2) as far
as it will go (18/a).
■
Tighten knurled nut (18/3) by hand.
5.8 Connecting the heater and lighting plug
(19)
1. Connect the plug parts (19/1) for the heater
and lighting.
2. Secure the plug connection.
5.9 Fitting the snow discharge spout (20-
23)
1. Apply spray oil (or grease) to the sliding sur-
face (20/1) of the snow discharge spout on
the snow blower.
2. Place the plastic ring (20/2) on the sliding
surface of the snow discharge spout (20/a)
and lightly oil it with spray oil (lubricating
grease can also be used).
38
3. Fit the snow discharge spout (21/1) (21/a, 22/
a).
4. Insert the mounting bolts (22/2) through the
brackets and snow discharge spout from the
inside.
5. Secure the snow discharge spout with the
self-locking nuts (22/3).
6. Insert the mounting bolts (23/1) through the
large guide plate (23/2) and fit the two small
guide plates (23/3).
Note: The small guide plates must lie on top
of the large guide plate.
7. Insert the guide plates with the mounting
bolts from below into the snow discharge
spout.
8. Fit washers (23/4) onto the bolts.
9. Securely tighten the self-locking nuts (23/5).
5.10 Connecting the Bowden cable to the
discharge flap (24)
This Bowden cable moves the discharge flap of
the snow discharge spout and serves to set the
discharge height.
1. Hook the Bowden cable into the guides (24/1,
24/2). The rubber sheath must be attached to
the outer Bowden cable.
2. Tighten lock nuts (24/3, 24/4) firmly against
the guide until the Bowden cable is taut.
3. Use the lever for setting the discharge height
to check the length of the Bowden cable:
■
Move the lever all the way to the front.
The discharge flap must move all the way
down.
■
Move the lever all the way to the rear.
The discharge flap must move all the way
up.
■
If necessary, change the length of the
Bowden cable.

5.11 Attaching the Bowden cable (25)

1. Attach the Bowden cable (25/1) into the
mount (25/2) under the engine.

6 START-UP

WARNING! Risk of injury from faulty ap-
pliance. Operation of an faulty appliance can re-
sult in serious injury and damage to the appli-
ance.
■
Operate the appliance only when it is undam-
aged and has not defects, and when no parts
are missing or loose.
