Symbol Meaning
Rotating parts in the discharge ar-
ea! Risk of entanglement!
2.5.2

Operating signs

Symbol
Choke
CLOSE / OPEN
Throttle
Slow / Fast
Engine key
On / Off
Fuel cock
OFF (closed)
ON (open)
Primer button
Auger drive
Start / stop
32
Meaning
Symbol
Travel drive
Start / stop
Steer snow blower to
the left / right
Align snow discharge
spout with crank
Adjust snow discharge
height with lever
2.6

Product overview 700.4 E LED (01)

No. Component
1 Heated handles
2 Clutch lever for the auger drive
3 Clutch lever for the travel drive
4 Hand crank for adjusting the discharge
direction
5 Lever for setting the discharge height
