5.3. DISPLAY ENVIRONMENTAL PARAMETERS VALUES
The instrument allows the real-time display of the modules' irradiance
and temperature values. The temperature measurement of the
modules is ONLY possible if it is coupled to a Master unit). The
measurements are performed using probes connected to it. It is also
possible to measure the angle of inclination of the modules (tilt
angle).
1. Switch on the instrument by pressing key
2. Connect one reference cell HT305 to input INP1 in case of
Monofacial modules. The instrument automatically detects the
[Off]
presence of the cell, providing the value of irradiance expressed in
W/m 2 . The screen to the side appears on the display
3. In case of Bifacial modules, connect the three reference cells
HT305 to the inputs INP1...INP3: (INP1 for Front Irr., and INP2 and
INP3 for Back Irr.). The instrument automatically detects the
Tmp/A
presence of the cells, providing the corresponding values of
[Off]
irradiance expressed in W/m
the display
4. Connect the PT305 temperature probe to the INP4 input. The
instrument recognizes the presence of the probe ONLY after
being coupled to a Master instrument (see § 5.2.3) providing the
Tmp/A
module temperature value expressed in °C. The screen to the side
[°C]
is shown on the display
43
5. Rest the remote unit onto the modules' surface. The instrument
automatically provides the value of the module's tilt angle with
respect to the horizontal plane, expressed in [°]. The screen to the
Tmp/A
side appears on the display
[Tilt]
25
The values read in real time are NOT saved in the
internal memory
2
. The screen to the side appears on
