2. GENERAL DESCRIPTION
The remote unit SOLAR03 has been designed to measure irradiance
2
[W/m ] and temperature [°C] both on Monofacial and Bifacial
photovoltaic modules by means of the relevant probes connected
to it.
The unit has been designed for use in combination with a Master
instrument, to carry out measurements and recordings during
maintenance operations on photovoltaic installations.
The unit can be connected to the following Master instruments and
accessories:
HT MODEL
PVCHECKs-PRO
I-V600, PV-PRO
HT305
PT305
Table 1: List of master instruments and accessories
The remote unit SOLAR03 has the following characteristics:
➢ Measurement of tilt angle of PV panels
➢ Connection to irradiance and temperature probes
➢ Real-time display of irradiance and temperature values of PV
modules
➢ Connection to a Master unit via Bluetooth connection
➢ Synchronization with a Master unit to start recordings
➢ Power supply through alkaline or rechargeable batteries with
USB-C connection
26
DESCRIPTION
Master instrument – Bluetooth BLE
connection
Irradiance sensor
Temperature sensor
SOLAR03
