3. Acquiring PANO Images
Click
These sub-modes
activated
14
Age Group
Child
Adult
X-ray intensity (Hard, Normal, Soft) is according to the
operator's decision.
NOTE
Soft ≤ Normal ≤ Hard
4. Select the patient's arch type under
Arch Selection. By default, Normal is
selected.
Orthogonal Mode: This mode enables
overlapping regions of teeth to be
minimized when acquiring images in the
ROI. If orthogonal arch is selected, its
sub-modes are activated.
5. Select the ROI for panoramic image
acquisition under PANO Examination.
6 . T h e p a t i e n t ' s g e n d e r w i l l b e
automatically selected according to
the patient information registered in
EasyDent. Nevertheless, ensure that this
information is correct.
Man
Woman
7. Select X-ray intensity.
VATECH's Standard
≤ 12
≥ 13
