oxycom ROOFTOP 3000 Installationsanleitung Seite 61

BEILAGE VIII:
L1 N PE
ROOFTOP 3000 ER:
check if the wire is connected to
J5-8 and not J5-7 on the mainboard
ROOFTOP 3000ER Retourventilator AC
EXHAUSTFAN
TRANSFORMER
A
DAMPER ACTUATOR
DAMPER ACTUATOR_ ON-OFF
SWITCH TO R
DAMPER ACTUATOR
DAMPER ACTUATOR_ ON-OFF
SWITCH TO L
K6B
X1
PE
N
L
X1
10
0 VOLT
ANALOOG OUT
FILTER SWITCH
VALVE WTW
STEP 5
STEP 4
STEP 3
STEP 2
STEP 1
+24 VOLT
VENTILATION
COOLING
HEAT RECOVERY
FROM THE BUILDING
Ø 400 mm
B
D
K6A
24V DC
9
8
7
6
5
4
3
2
1
- 62 -
MAX. VOLUME
MODE VALVE A VALVE B
VENITILATION AIR
CLOSED OPEN
3000 m /h 3
CLOSED OPEN
3
3000 m /h
OPEN CLOSED
1500 m /h 3
A
P
B
P = 150 Pa
P
D D D
K5A K4A K3A
24V DC 24V DC 24V DC
MAX. PRESSURE
VENTILATER
50 Pa
50 Pa
500 Pa
TO SEC. SIDE ROOFTOP
Ø 400 mm
D D
K2A K1A
24V DC 24V DC
