RELEVANCE OF EXTRACTION PRESSURE

• The gauge needle indicates the extraction pressure.
• A pressure within the "ESPRESSO RANGE" highlighted in grey on the gauge is ideal.
• When the gauge needle is below the "ESPRESSO RANGE" during extraction,
this indicates the espresso has been extracted with insufficient pressure. This can
happen when the water flow through the ground coffee is too fast, resulting in an
under-extracted espresso that is watery, cold and lacks crema and flavor. Possible
causes for under-extraction include the grind being too coarse, insufficient coffee
in the filter, insufficient tamping, or a combination of any of these. To resolve this:
• Select a finer coffee grind and retry.
• Increase the amount of coffee and retry.
• Increase the tamping pressure and retry.
• When the gauge needle is beyond the "ESPRESSO RANGE" during extraction,
this indicates the espresso has been extracted with too much pressure. This can
happen when the water flow through the ground coffee is too slow, resulting in
an over-extracted espresso that is very dark and bitter with a mottled and uneven
crema. Possible causes for over-extraction include the grind being too fine, too
much ground coffee in the filter, over tamping or a combination of any of these.
To resolve this:
• Select a coarser coffee grind and retry.
• Decrease the amount of coffee and retry.
• Decrease the tamping pressure and retry.
CUSTOMIZING THE VOLUME OF ESPRESSO, CAPPUCCINO AND LATTE
MACCHIATO
• When the appliance has finished preheating, keep the "Espresso" button pressed
for approx. 3 seconds. The "Espresso", "Cappuccino", and "Latte Macchiato" button
indicators flash alternately in green. The appliance is now ready to customize
the volume.
NOTE
If there is no action within 15 seconds, the appliance will return to standby mode.
• Customizing the Espresso volume (20-200ml):
1. To customize the volume of a single shot espresso, press the "Espresso" button
once. To customize the volume of a double shot espresso, press the "Espresso"
button twice. In both cases, an acoustic signal sounds 3 times and the appliance
starts the brewing process.
2. When the desired amount of espresso is reached, press the "Espresso" button
again to stop the brewing process. An acoustic signal sounds 3 times, indicating
that the volume has been customized successfully. The appliance returns to
standby mode.
36
• Customizing the Cappuccino volume (20-200ml espresso, 6-60 seconds of milk
frothing):
1. To customize the volume of a small cup of cappuccino, press the "Cappuccino"
button once. To customize the volume of a large cup of cappuccino, press the
"Cappuccino" button twice. In both cases, an acoustic signal sounds 3 times
and the appliance starts frothing milk.
2. When the desired amount of frothed milk is reached, press the "Cappuccino"
button again to stop the frothing process and start the espresso brewing process.
3. When the desired amount of espresso is reached, press the "Cappuccino"
button again to stop the brewing process. An acoustic signal sounds 3 times,
indicating that the volume has been customized successfully. The appliance
returns to standby mode.
• Customizing the Latte Macchiato volume (20-200ml espresso, 6-60 seconds of
milk frothing):
1. To customize the volume of a small cup of latte macchiato, press the "Latte
Macchiato" button once. To customize the volume of a large cup of latte
macchiato, press the "Latte Macchiato" button twice. In both cases, an acoustic
signal sounds 3 times and the appliance starts frothing milk.
2. When the desired amount of frothed milk is reached, press the "Latte Macchiato"
button again to stop the frothing process and start the espresso brewing process.
3. When the desired amount of espresso is reached, press the "Latte Macchiato"
button again to stop the brewing process. An acoustic signal sounds 3 times,
indicating that the volume has been customized successfully. The appliance
returns to standby mode.
• Resetting to default volumes:
Keep both the "Espresso" and "Cappuccino" pressed for approx. 5 seconds. The
appliance is now reset to its original default settings.

ADDING FROTHED MILK/FROTHING MILK MANUALLY

1. Place your previously brewed beverage or an empty cup on the drip plate. Turn
the milk wand knob so that the milk wand points at the cup.
2. Keep the "Cappuccino" button pressed for approx. 3 seconds. The appliance
starts frothing milk . The "Cappuccino" button indicator flashes blue and green
alternately.
3. Press the "Cappuccino" button again to stop the milk frothing when the desired
amount is reached.
